Description

Knapen Biomass PLUS Walking Floor

This our upgraded Biomass PLUS spec trailer created for the market by the market. You spoke, we listened.

Following our 'Horses for courses' philosophy and plugging the gap between our BIOMASS and RECYCLING specs, this trailer has been carefully specifed for the transport of Biomass, light waste & recycling products. While it will cope significantly better with harsh loading practices, the tare weight is just 8800kgs with manual sheet keeping your payload potential as high as possible.

It features all the Heavy Duty spec items from the RECYCLING spec Knapen and combines them with a 15 x 10mm Cargoofloor system and smaller wear plates to the sidewalls.

This trailer is built to withstand heavier use - the chassis and sidewall construction is proven in the Eastern European waste sector at 55 tonnes. Knapen - who make over 30 trailers per week are the largest constructor in Europe. You can learn things over 30 years in Latvia, Poland, Russia etc. Bad roads and bad use.

Whilst optimised for tipping on hard standing sufaces (MRF facilities, incinerator plants, modern landfill sites)  the uprated spec means it can handle to occasional trip on the pile if required, though not recommended for everyday work on the landfill (we do the TITAN walking floor option for that).

The main feature that will appeal to most is the Heavy duty steel box section that covers all four sides of the box as these are the areas of the trailer that take the most abuse. This HD protection is bolted on, braced at all 4 corners and in the centre with a HD tie bar and can take those knocks that inevitably come from loading shovels. It will dent up and mark but it can be easily cut out and replaced without breaking down the trailer itself. If 130 cuyd is not enough for you we can build 140 cuyd and 150 cuyd variants to this. Too heavy for you then choose the BIOMASS spec Knapen. Too light for you then choose the TITAN Armageddon specification trailer.

127 cuyd 4.2m over the side
K100 Baltic Chassis (18 tonne pin construction). This trailer was originally designed to cope with the heavy use and poor roads of the Baltic states. The kinpin has steel construction and extra bearers compared to the STANDAD BIOMASS and Standard floors.
Cargo Floor 15 x 10mm plank system
Maximum floor bearers
Thicker than standard cross members full length
8 more cross members than standard
Heavy duty UK steel lead up plate
BPW Drum brake axles
2m (H) x 3m (L) x 4 mm Triangular wear plates
Front catwalk
Steel capped top rails 600 mm x 600 mm x 6 mm steel box capping both sides, front and rear attached by tabs and bolts.
Extra heavy duty roof supports
Moving internal headboard
Towing eye in case you have been a bit cheeky
Choice of roof systems: Double manual or automatic net systems or manual or automatic sheet systems
Rear door 50 50 split with double locks per door (hydraulic door variant available to order)
Automatic safety door lock.

Knapen BIOMASS PLUS specification trailer
