125 cuyd alloy body on a K100 steel galvanised chassis
Tri axle on air
DCA axles and disc brakes
Alloy wheels
Cargo Floor 21 plank x 10mm aluminium foor system
Dawbarn Hydroclear automatic sheet system
50:50 barn doors with air operated rear door safety lock
Unique wider extruded planks that are fully seam welded (many competitors reduce cost by only stitch welding - not advised in plank side construction!)
Full robot side welding, door welding and headboard welding for perfection every time
Conical body shape gives a better discharge
Front headboard sidewall cast alloy joiners which prevent the headboard from splitting away
4 extra cross members at rear of trailer for forklift loading
UK reinforced lead up plate and a heavy duty king pin, 18 tonne capability (Knapen being Dutch are used to 55 tonne total weight)
2 extra pairs of working lights by the landing legs and behind the rear axle
Moving internal headboard
Wander lead remote control
Pneumatic floor mat
Side impact bars and rear underrun bar with towing eye
Catwalk and toolbox
*this estimator is not an offer to finance
Stock No. | SN16401 |
---|---|
Type | Biomass Moving Floor Trailer |
Chassis | Knapen |
Body | Knapen |
Year | 2014 |
MOT | 02/2024 C382499 |
Cost | £25,000 |
Documents | ![]() |
eCO2 | 75000kg |
---|---|
Confidence | 1 (low) |
Checked | 16/11/2022 |
Weight | 8400kgs |
---|---|
Type | Steel Sub-Frame |
Suspension | Air |
Brakes | 22.50" Knorr Bremse SK7 Disc |
ABS/EBS | WABCO |
Wheels | Alloy |
Axles | 3x DCA TE5/8N |
Volume | 125 CuYds (95.6m3) |
---|---|
Door | Barn Door 50:50 |
Catwalk | ![]() |
Floor System | Cargo CF500SL2 |
Floor Slats | 21x 10mm Smooth |
Floor Parts | |
Headboard | Moving |
Chassis | Galvanised |
Body | White |
Cover | Orange Dawbarn Hydraulic Roll Over Sheet Hydroclear |
