| Year | 2021 |
|---|---|
| Chassis | Knapen Trailers BV. |
| Body | Knapen Trailers BV. |
| Volume | 130 CuYds (99.4m3) |
| Weight | 8100kgs |
| Stock No. | SN18925 |
|---|---|
| Type | Biomass Moving Floor Trailer |
| Chassis | Knapen |
| Body | Knapen |
| Model | K100 |
| Year | 2021 |
| MOT | C542239 |
| Documents |  Parts Manual |
| eCO2 | 75000kg |
|---|---|
| Confidence | 1 (low) |
| Checked | 16/11/2022 |
| Weight | 8100kgs |
|---|---|
| Type | Alloy Sub-Frame |
| Suspension | Air |
| Brakes | 22.50" SAF SBS Disc |
| ABS/EBS | WABCO EBS-E |
| Wheels | Steel |
| Axles | 3x SAF BI9 22S SBS |
| Volume | 130 CuYds (99.4m3) |
|---|---|
| Door | Barn Door 50:50 |
| Catwalk |  |
| Floor System | Cargo CF500SL-C |
| Floor Slats | 21x 10mm Smooth |
| Floor Parts | |
| Headboard | Moving |
| Chassis | Galvanised |
| Body | White RAL 9010 |
| Cover | Ultra Blue Dawbarn Hydraulic Roll Over Sheet Hydroclear |
130 cuyd on a K100 steel galvanised chassis
Tri axle on air
SAF off-road axles and SAF disc brakes
21 plank x 10mm Floor which is the stronger aluminium flat Cargo Floor system, compared to the 6mm version
Dawbarn Hydroclear automatic sheet system - 900g sheet!
50:50 barn doors with air operated rear door safety lock
2000x1000 x 3mm internal wear plates for extra resistance
Unique wider extruded planks that are fully seam welded
Full robot side welding, door welding and headboard welding for perfection every time
Conical body shape gives a better discharge
Front headboard sidewall cast alloy joiners which prevent the headboard from splitting away
4 extra cross members at rear of trailer for forklift loading
UK reinforced lead up plate and a heavy duty king pin, 18 tonne capability
Side impact bars and rear underrun bar
Catwalk and toolbox
