| Year | 2020 |
|---|---|
| Chassis | Knapen Trailers BV. |
| Body | Knapen Trailers BV. |
| Volume | 120 CuYds (91.7m3) |
| Weight | 7950kgs |
| Stock No. | SN19190 |
|---|---|
| Type | Biomass Moving Floor Trailer |
| Chassis | Knapen |
| Body | Knapen |
| Year | 2020 |
| MOT | 11/2026 C534025 |
| Documents |  Parts Manual |
| eCO2 | 75000kg |
|---|---|
| Confidence | 1 (low) |
| Checked | 16/11/2022 |
| Weight | 7950kgs |
|---|---|
| Type | Steel Sub-Frame |
| Suspension | Air |
| Brakes | 22.50" SAF SBS Disc |
| ABS/EBS | WABCO EBS-E |
| Wheels | Steel |
| Axles | 3x SAF BI9 22S SBS |
| Volume | 120 CuYds (91.7m3) |
|---|---|
| Door | Barn Door 50:50 |
| Catwalk |  |
| Floor System | Cargo CF500SL-C |
| Floor Slats | 21x 10mm Smooth |
| Floor Parts | |
| Headboard | Moving |
| Chassis | Galvanised |
| Body | White YT90 |
| Cover | Mid Blue Dawbarn Hydraulic Roll Over Sheet Hydroclear |
120 cuyd on a K100 steel galvanised chassis – 10 Year rust warranty
Tri axle on air
SAF off-road axles and Knorr Bremse disc brakes
21 plank x 10mm Floor which is the stronger aluminium flat Cargo Floor system, compared to the 6mm version
Dawbarn hydroclear automatic sheet system with remote
50:50 barn doors with air operated rear door safety lock
Front headboard sidewall cast alloy joiners which prevent the headboard from splitting away
4 extra cross members at rear of trailer for forklift loading
UK reinforced lead up plate and a heavy duty king pin, 18 tonne capability (Knapen being Dutch are used to 55 tonne total weight)
Additional pair of working lights behind the third axle
Moving internal headboard
Wander lead remote control
Side impact bars and rear underrun bar
Catwalk and toolbox
*this estimator is not an offer to finance
120 cuyd on a K100 steel galvanised chassis – 10 Year rust warranty
Tri axle on air
SAF off-road axles and Knorr Bremse disc brakes
21 plank x 10mm Floor which is the stronger aluminium flat Cargo Floor system, compared to the 6mm version
Dawbarn hydroclear automatic sheet system with remote
50:50 barn doors with air operated rear door safety lock
Front headboard sidewall cast alloy joiners which prevent the headboard from splitting away
4 extra cross members at rear of trailer for forklift loading
UK reinforced lead up plate and a heavy duty king pin, 18 tonne capability (Knapen being Dutch are used to 55 tonne total weight)
Additional pair of working lights behind the third axle
Moving internal headboard
Wander lead remote control
Side impact bars and rear underrun bar
Catwalk and toolbox
*this estimator is not an offer to finance
| Stock No. | SN19190 |
|---|---|
| Type | Biomass Moving Floor Trailer |
| Chassis | Knapen |
| Body | Knapen |
| Year | 2020 |
| MOT | 11/2026 C534025 |
| Documents | Parts Manual |
| eCO2 | 75000kg |
|---|---|
| Confidence | 1 (low) |
| Checked | 16/11/2022 |
| Weight | 7950kgs |
|---|---|
| Type | Steel Sub-Frame |
| Suspension | Air |
| Brakes | 22.50" SAF SBS Disc |
| ABS/EBS | WABCO EBS-E |
| Wheels | Steel |
| Axles | 3x SAF BI9 22S SBS |
| Volume | 120 CuYds (91.7m3) |
|---|---|
| Door | Barn Door 50:50 |
| Catwalk | |
| Floor System | Cargo CF500SL-C |
| Floor Slats | 21x 10mm Smooth |
| Floor Parts | |
| Headboard | Moving |
| Chassis | Galvanised |
| Body | White YT90 |
| Cover | Mid Blue Dawbarn Hydraulic Roll Over Sheet Hydroclear |
