New 2023 Titan Landfill Walking Floor® Trailer
360 view Click for 360 view
360 View
New 2023 Titan Landfill Walking Floor® Trailer
New 2023 Titan Landfill Walking Floor® Trailer
YouTube Video
Video
New 2023 Titan Landfill Walking Floor® Trailer
New 2023 Titan Landfill Walking Floor® Trailer
Photo 1
New 2023 Titan Landfill Walking Floor® Trailer
New 2023 Titan Landfill Walking Floor® Trailer
Photo 2
New 2023 Titan Landfill Walking Floor® Trailer
New 2023 Titan Landfill Walking Floor® Trailer
Photo 3
New 2023 Titan Landfill Walking Floor® Trailer
New 2023 Titan Landfill Walking Floor® Trailer
Photo 4
New 2023 Titan Landfill Walking Floor® Trailer
New 2023 Titan Landfill Walking Floor® Trailer
Photo 5

Landfill Walking Floor® Trailer

Year 2023 (new)
Chassis Titan Trailers Inc
Body Titan Trailers Inc
Volume 130 CuYds (99.4m3)
Weight 9860kgs

Full Specifications

Specifications

Chassis:

Weight 9860kgs
Type Alloy Sub-Frame
Suspension Air
Brakes 22.50" SAF SK7 Disc
ABS/EBS WABCO EBS-E
Wheels Alloy
Axles 3x SAF B9 22K01

Body:

Volume 130 CuYds (99.4m3)
Door Barn Door 50:50
Floor System Cargo CF500SL-C
Floor Slats 15x 22mm XHDI
Floor Parts
Chassis Natural
Body RAL 9010 White
Cover Net Titan Hydraulic Net System 50:50 Split
Specifications

Parts Manual


For a printable parts manual for this trailer click below


Parts Manual

Description

TITAN Moving Floor For Sale

Full Description

Description

TITAN Moving Floor For Sale

THE KING OF LANDFILL & HEAVY WASTE
Unique patented design and construction methods combine to give superior strength at very low weight with the lowest possible whole life cost
130 cuyd capacity so larger than standard trailer size
EXTRA Heavy duty top rail
One of the best reasons to buy a Titan Moving Floor: ZERO TIE BARS - this is a huge advantage over all the competition and no other manufacturer can produce an aluminium upper-structure strong enough to do this!
Patented longitudinal panel design allowing for optimised sidewall design
Super Heavy Duty side wall for the 2 x base side panels (thicker than traditional Horizontal panels with an added wear plate)
Extra Heavy Duty side wall for the upper side panels
Side wall fully seam welded on both the OUTSIDE and the INSIDE - no one other than TITAN can do this
Cargo Floor 15 Plank XHDI Floor. 10-22mm!
SAF Disc Brakes
50:50 barn doors
TITAN Automatic Net System - no one even gets close to the capability and reliability of this net system
Front Man Door and step - to access trailer from the front
Automatic Door Safety Lock at Base - stand clear in safety when you release the load
EXPLOSION WELDED STEEL TO ALUMINIUM rubbing plate - again unique to TITAN - generates massive strength and weight savings

Titan Inc of Canada are North Americas' largest Waste or Garbage Walking Floor Manufacturer. They now have a UK factory based in Middlesbrough making 4 to 10 per week - this trailer will out last any other by up to double the life span - proven capability in the UK since 2003 - 100s in service with companies like Sherwoods. The Titan have completely different DNA from European types. They are lighter like for like. They have horizontal side wall planks. The planks are all different with thicker faces at the base working the way up the side wall. Strength where you need it. The top rail is like no other. This means the trailer has no cross ties in the body. So nothing for the loader to hit. The trailer side wall is welded on the inside and again uniquely on the OUTSIDE - giving massive strength increase. New technologies are on show throughout - TITAN weld STEEL to ALUMINIUM - expensive but creating far lighter construction than the competition.

Titan Trailer for Sale; Titan Heavy Waste Specification For Sale

Description

Finance Estimator


Own this Landfill Walking Floor® Trailer from £428.62 per week


Get An Estimate

Own from £428.62 per week*

Initial Payment


Finance Duration


Final Payment

Residual Value

£
Final Payment

Payments

per month
( per week)

Interest Rate

comparison rate
Flat Rate

Total Paid

(excluding initial)
interest

*this estimator is not an offer to finance

Finance

Quote


For a printable quote for this trailer click below


Get a Quote


Description

TITAN Moving Floor For Sale

THE KING OF LANDFILL & HEAVY WASTE
Unique patented design and construction methods combine to give superior strength at very low weight with the lowest possible whole life cost
130 cuyd capacity so larger than standard trailer size
EXTRA Heavy duty top rail
One of the best reasons to buy a Titan Moving Floor: ZERO TIE BARS - this is a huge advantage over all the competition and no other manufacturer can produce an aluminium upper-structure strong enough to do this!
Patented longitudinal panel design allowing for optimised sidewall design
Super Heavy Duty side wall for the 2 x base side panels (thicker than traditional Horizontal panels with an added wear plate)
Extra Heavy Duty side wall for the upper side panels
Side wall fully seam welded on both the OUTSIDE and the INSIDE - no one other than TITAN can do this
Cargo Floor 15 Plank XHDI Floor. 10-22mm!
SAF Disc Brakes
50:50 barn doors
TITAN Automatic Net System - no one even gets close to the capability and reliability of this net system
Front Man Door and step - to access trailer from the front
Automatic Door Safety Lock at Base - stand clear in safety when you release the load
EXPLOSION WELDED STEEL TO ALUMINIUM rubbing plate - again unique to TITAN - generates massive strength and weight savings

Titan Inc of Canada are North Americas' largest Waste or Garbage Walking Floor Manufacturer. They now have a UK factory based in Middlesbrough making 4 to 10 per week - this trailer will out last any other by up to double the life span - proven capability in the UK since 2003 - 100s in service with companies like Sherwoods. The Titan have completely different DNA from European types. They are lighter like for like. They have horizontal side wall planks. The planks are all different with thicker faces at the base working the way up the side wall. Strength where you need it. The top rail is like no other. This means the trailer has no cross ties in the body. So nothing for the loader to hit. The trailer side wall is welded on the inside and again uniquely on the OUTSIDE - giving massive strength increase. New technologies are on show throughout - TITAN weld STEEL to ALUMINIUM - expensive but creating far lighter construction than the competition.

Titan Trailer for Sale; Titan Heavy Waste Specification For Sale


Own from £428.62 per week*

Initial Payment


Finance Duration


Final Payment

Residual Value

£
Final Payment

Payments

per month
( per week)

Interest Rate

comparison rate
Flat Rate

Total Paid

(excluding initial)
interest

*this estimator is not an offer to finance

Specifications

Chassis:

Weight 9860kgs
Type Alloy Sub-Frame
Suspension Air
Brakes 22.50" SAF SK7 Disc
ABS/EBS WABCO EBS-E
Wheels Alloy
Axles 3x SAF B9 22K01

Body:

Volume 130 CuYds (99.4m3)
Door Barn Door 50:50
Floor System Cargo CF500SL-C
Floor Slats 15x 22mm XHDI
Floor Parts
Chassis Natural
Body RAL 9010 White
Cover Net Titan Hydraulic Net System 50:50 Split
