Recycling Moving Floor Trailer

Year 2024 (new)
Chassis Knapen Trailers BV.
Body Knapen Trailers BV.
Volume 127 CuYds (97.1m3)
Weight 9450kgs

Full Specifications

Specifications

Chassis:

Weight 9450kgs
Type Steel Sub-Frame
Suspension Air
Brakes 22.50" BPW Drum
ABS/EBS ZF CV Distribution UK Ltd EBS-E
Wheels Steel
Axles 3x BPW Eco Plus

Body:

Volume 127 CuYds (97.1m3)
Door Barn Door 50:50
Catwalk ./
Floor System Cargo CF500SL2
Floor Slats 21x 20mm XHDI
Floor Parts HeavyDuty Impact
Headboard Moving
Chassis Galvanised
Body White RAL 9010
Cover Net Dawbarn Hydraulic Net System 50:50 Split
Specifications

Parts Manual


For a printable parts manual for this trailer click below


Parts Manual

Description

Knapen RECYCLING Waste Walking Floor

Full Description

Description

Knapen RECYCLING Waste Walking Floor

This is our RECYCLING Waste walking floor product. Floors are definitely a case of 'Horses for Courses'. Choose the right spec trailer for the work you do. We have optimised this RECYCLING trailer to take abuse at the heavier end of the market. It has features that move it up from a BIOMASS spec into the more difficult products you might carry when RECYCLING. The chassis and sidewall construction is a culmination of 30 years experience building for the Eastern European waste sector at 55 tonnes. The floor is the XHDI - extra heavy duty impact system - will take larger lumps - more abrasive materials - larger wood items, black bag and household recycling products. Though not recommended for everyday work on the landfill (we do the TITAN walking floor option for that) - it will withstand some landfill when the MERF occasionally breaks down. This trailer has a large steel box section bolted to the of all four sides of the box and can take those knocks that inevitably come from loading shovels. other sizes are available. Too heavy for you then choose the BIOMASS spec Knapen, not strong enough then choose the TITAN Armageddon specification trailer.
127 cuyd 4.2m over the side
K100 HDX Subframe/Chassis with 8 additional cross-members and all cross-members thicker by design than STANDARD & BIOMASS floors. This Subframe/chassis was originally designed to cope with the heavy use and poor roads of the Baltic states. It features a Heavy Duty Steel lead up plate and Kingpin rated at 18 tonnes.

Cargo Floor 21 plank HD (Heavy Duty) system. 8mm - 20mm of aluminium on the planks
BPW Axles and BPW Drum brakes
Galvanised chassis with 10 year anti corrosion warranty
6 meters of 2 m full height 4 mm wear plates and 7 meters of 1 m height 4 mm wear plates
Steel capped top rails 600 mm x 600 mm x 6 mm steel box capping both sides, front and rear attached by tabs and bolts.
Extra heavy duty roof supports
Dawbarn Slew Ring Hydraulic 50:50 net system with a manual lever
Moving internal headboard
Towing eye in case you have been a bit cheeky
Rear door 50:50 split with double locks per door (hydraulic door variant available to order) with an air safety door lock
Double front catwalk
Knapen Waste Specification Walking Floor
