Watertight Waste Tipping Trailer

Year 2024 (new)
Chassis SDC Trailers Limited
Body SDC Trailers Limited
Volume 65 CuYds (49.7m3)
Weight 6500kgs

Full Specifications

Specifications

Chassis:

Weight 6500kgs
Type Steel Straight Frame
Suspension Air
Brakes 22.50" BPW Drum
ABS/EBS Haldex Europe SAS Gen 3
Wheels Steel
Axles 3x BPW Eco Plus
Axle 1 Lift
Axle 2 Fixed
Axle 3 Fixed

Body:

Volume 65 CuYds (49.7m3)
Door Auto Straight
Catwalk ./
Chassis Red
Body Grey
Cover Truck Red Dawbarn Manual Roll Over Sheet Domed
Specifications

Parts Manual


For a printable parts manual for this trailer click below


Parts Manual

Description

SDC Watertight Tipping Trailer For Sale (50mm thick, 4.2 mm inside skin, 2.8 mm outside skin)

Full Description

Description

SDC Watertight Tipping Trailer For Sale (50mm thick, 4.2 mm inside skin, 2.8 mm outside skin)

64 cuyd alloy body and a steel straight frame chassis

Triaxle axle on air with a front lift axle

BPW axles and BPW drums brakes

Side Wall: 50 mm thick aluminium plank-sided wall. 4.2 mm inside skin, 2.8 mm outside skin. Planks are clipped together, then fully seam-welded on the inside. 45 degree side profile at base. Headboard: 4mm, with full width platform (mesh base) with ladder on offside.

Dawbarn manual roll over sheet with surge plates on the front and rear including a rear sheet handle so it can be wound from the ground

Turner autogate door

Rear taildoor prop and ladder

SDC Tipping Trailer For Sale; Watertight Tipping Trailer for Sale; Food waste tipping trailer for sale

Reasons to Buy This SDC Watertight Food & Rendering Waste Trailer

SDC is the UK's largest trailer manfucturer producting nearly 10,000 trailers per annum.  Newton have worked with SDC for 26 years to produce this trailer with many hundreds of this watertight trailer in use.

The trailer is specifically designed to cope with the difficulty of carrying waste materials with a high liquid content. The floor is 8 mm thick towards the rear. The sides are almost 2 x thicker than a standard plank sider at 4.2 mm thick. Compare this to the competition. Why? - so that bones and cattle horns will not penetrate. Also in use the side will last longer and stay watertight longer.

The rear door has seal on all FOUR sides (including the top). The door is massively reinforced to cope with the liquid pressures. The door then has an over center TURNER AUTOGATE clamp system which means the door will not jump the locks and hurt the driver when discharging.

The trailer has surge plates bolted on at the front and back and a special sheet to withstand surge.

EACH AND EVERY trailer is then part filled with water and tipped and left overnight for inspection of drips. We do many variants - some with internal doors - feathers one side, guts the other. Some with drainage - taps and drainage plates down the full length.
