Hire New 2023 STAS Watertight Tipping Trailer
360 view Click for 360 view
360 View
Hire New 2023 STAS Watertight Tipping Trailer
Hire New 2023 STAS Watertight Tipping Trailer
YouTube Video
Video
Hire New 2023 STAS Watertight Tipping Trailer
Hire New 2023 STAS Watertight Tipping Trailer
Photo 1
Hire New 2023 STAS Watertight Tipping Trailer
Hire New 2023 STAS Watertight Tipping Trailer
Photo 2
Hire New 2023 STAS Watertight Tipping Trailer
Hire New 2023 STAS Watertight Tipping Trailer
Photo 3
Hire New 2023 STAS Watertight Tipping Trailer
Hire New 2023 STAS Watertight Tipping Trailer
Photo 4
Hire New 2023 STAS Watertight Tipping Trailer
Hire New 2023 STAS Watertight Tipping Trailer
Photo 5

Watertight Tipping Trailer

Year 2023 (new)
Chassis STAS Konstructiewerkhuizen
Body STAS Konstructiewerkhuizen
Volume 68 CuYds (52.0m3)
Weight 6250kgs

Full Specifications

Specifications

Chassis:

Weight 6250kgs
Type Alloy Straight Frame
Suspension Air
Brakes 22.50" SAF SBS Disc
ABS/EBS WABCO 2S/2M
Wheels Steel
Weigher VWS
Axles 3x SAF BI9 22S SBS
Axle 1 Lift
Axle 2 Fixed
Axle 3 Fixed

Body:

Volume 68 CuYds (52.0m3)
Door Auto Inclined
Catwalk ./
Chassis DAF Grau C4P500
Body RAL 7004 Signal Grey
Cover Seawolf Blue (Grey) Dawbarn Manual Roll Over Sheet Domed
Specifications

Parts Manual


For a printable parts manual for this trailer click below


Parts Manual

Description

STAS Watertight Plank Sided Tipping Trailer For Sale

Full Description

Description

STAS Watertight Plank Sided Tipping Trailer For Sale

Aluminium chassis on 1400 mm beam centers straightframe

Triaxle on SAF Axles

Front Lift Axle - auto lift auto drop

Jost Manual Landing Legs - saving 80 kgs

Steel Rims

VWS weigher with chassis mounted readout

600 mm wide plank with robot welding.

6 mm ultrahard floor alloy floor single piece full length with 24 cross bearers.

Surge plates

Catwalk

Painted body and painted chassis

Leakproof rear door inclined with hydraulic locking mechanism on the left and right side. Pneumatic locking system on the bottom (two way pressure system). Oil pump for hydraulic locking is fitted on the UK driver side. 20 degree inclined rear door. Rubber sealed (special extra strong rubber single piece water tight)

4 closing hooks on the bottom with handle on driver side at the front side of the chassis for final safe door release.

Manual Or Dawbarn Automatic Roll Over Sheet with Remote Control

Newton Trailers Limited 01525 872466

STAS Bulker for Sale; STAS Tipping Trailer for Sale; STAS Bulk Tipping Trailer For Sale

Description

Description

STAS Watertight Plank Sided Tipping Trailer For Sale

Aluminium chassis on 1400 mm beam centers straightframe

Triaxle on SAF Axles

Front Lift Axle - auto lift auto drop

Jost Manual Landing Legs - saving 80 kgs

Steel Rims

VWS weigher with chassis mounted readout

600 mm wide plank with robot welding.

6 mm ultrahard floor alloy floor single piece full length with 24 cross bearers.

Surge plates

Catwalk

Painted body and painted chassis

Leakproof rear door inclined with hydraulic locking mechanism on the left and right side. Pneumatic locking system on the bottom (two way pressure system). Oil pump for hydraulic locking is fitted on the UK driver side. 20 degree inclined rear door. Rubber sealed (special extra strong rubber single piece water tight)

4 closing hooks on the bottom with handle on driver side at the front side of the chassis for final safe door release.

Manual Or Dawbarn Automatic Roll Over Sheet with Remote Control

Newton Trailers Limited 01525 872466

STAS Bulker for Sale; STAS Tipping Trailer for Sale; STAS Bulk Tipping Trailer For Sale


Specifications

Chassis:

Weight 6250kgs
Type Alloy Straight Frame
Suspension Air
Brakes 22.50" SAF SBS Disc
ABS/EBS WABCO 2S/2M
Wheels Steel
Weigher VWS
Axles 3x SAF BI9 22S SBS
Axle 1 Lift
Axle 2 Fixed
Axle 3 Fixed

Body:

Volume 68 CuYds (52.0m3)
Door Auto Inclined
Catwalk ./
Chassis DAF Grau C4P500
Body RAL 7004 Signal Grey
Cover Seawolf Blue (Grey) Dawbarn Manual Roll Over Sheet Domed
