| Year | 2024 (new) |
|---|---|
| Chassis | SDC Trailers Limited |
| Body | Wilcox Commercial Vehicles Limited |
| Volume | 62 CuYds (47.4m3) |
| Weight | 10500kgs |
| Stock No. | SN17867 |
|---|---|
| Type | Watertight Tipping Trailer |
| Chassis | SDC |
| Body | Wilcox CV |
| Model | Watertight Newton Wilcox |
| Year | 2024 (new) |
| MOT | 09/2027 C616281 |
| Documents |  Parts Manual |
| eCO2 | 55000kg |
|---|---|
| Confidence | 1 (low) |
| Checked | 16/11/2022 |
| Weight | 10500kgs |
|---|---|
| Type | Steel Step Frame |
| Suspension | Air |
| Brakes | 22.50" JOST UK SBS Disc |
| ABS/EBS | Haldex Europe SAS Gen 3 |
| Wheels | Steel |
| Weigher | VWS |
| Axles | 3x JOST UK |
| Axle 1 | Lift |
| Axle 2 | Fixed |
| Axle 3 | Fixed |
| Volume | 62 CuYds (47.4m3) |
|---|---|
| Door | Barn Door 50:50 |
| Catwalk |  |
| Floor Slats | 5mm |
| Floor Parts | |
| Chassis | DAF Grau C4P500 |
| Body | RAL 7004 Signal Grey |
| Cover | Seawolf Blue (Grey) Dawbarn Hydraulic Roll Over Sheet Hydroclear |
62 cuyd alloy body on a steel straight frame chassis
Tri axle on air with a front lift axle including override button
JOST Axles and disc brakes
VWS Wifi weigher
Top hung rear door with turner autogate lock
Surge plates at the front and the rear
Raise lower valve
62 cuyd alloy body on a steel straight frame chassis
Tri axle on air with a front lift axle including override button
JOST Axles and disc brakes
VWS Wifi weigher
Top hung rear door with turner autogate lock
Surge plates at the front and the rear
Raise lower valve
| Stock No. | SN17867 |
|---|---|
| Type | Watertight Tipping Trailer |
| Chassis | SDC |
| Body | Wilcox CV |
| Model | Watertight Newton Wilcox |
| Year | 2024 (new) |
| MOT | 09/2027 C616281 |
| Documents | Parts Manual |
| eCO2 | 55000kg |
|---|---|
| Confidence | 1 (low) |
| Checked | 16/11/2022 |
| Weight | 10500kgs |
|---|---|
| Type | Steel Step Frame |
| Suspension | Air |
| Brakes | 22.50" JOST UK SBS Disc |
| ABS/EBS | Haldex Europe SAS Gen 3 |
| Wheels | Steel |
| Weigher | VWS |
| Axles | 3x JOST UK |
| Axle 1 | Lift |
| Axle 2 | Fixed |
| Axle 3 | Fixed |
| Volume | 62 CuYds (47.4m3) |
|---|---|
| Door | Barn Door 50:50 |
| Catwalk | |
| Floor Slats | 5mm |
| Floor Parts | |
| Chassis | DAF Grau C4P500 |
| Body | RAL 7004 Signal Grey |
| Cover | Seawolf Blue (Grey) Dawbarn Hydraulic Roll Over Sheet Hydroclear |
