| Year | 2021 |
|---|---|
| Chassis | Knapen Trailers BV. |
| Body | Knapen Trailers BV. |
| Volume | 120 CuYds (91.7m3) |
| Weight | 8100kgs |
| Stock No. | SN15928 |
|---|---|
| Type | Biomass Moving Floor Trailer |
| Chassis | Knapen |
| Body | Knapen |
| Model | K100 |
| Year | 2021 |
| MOT | 08/2026 C559351 |
| Documents |  Parts Manual |
| eCO2 | 75000kg |
|---|---|
| Confidence | 1 (low) |
| Checked | 16/11/2022 |
| Weight | 8100kgs |
|---|---|
| Type | Alloy Sub-Frame |
| Suspension | Air |
| Brakes | 22.50" SAF SBS Disc |
| ABS/EBS | WABCO EBS-E |
| Wheels | Steel |
| Axles | 3x SAF BI9 22S SBS |
| Volume | 120 CuYds (91.7m3) |
|---|---|
| Door | Barn Door 50:50 |
| Catwalk |  |
| Floor System | Cargo CF500SL-C |
| Floor Slats | 21x 10mm Smooth |
| Floor Parts | |
| Headboard | Moving |
| Chassis | Galvanised |
| Body | White RAL 9010 |
| Cover | Seawolf Blue (Grey) Dawbarn Hydraulic Roll Over Sheet Hydroclear |
120 cuyd on a K100 steel galvanised chassis – 10 Year rust warranty
Tri axle on air
SAF off-road axles and SAF disc brakes
21 plank x 10mm Floor which is the stronger aluminium flat Cargo Floor system, compared to the 6mm version
Dawbarn Hydroclear automatic sheet system - 900g sheet!
50:50 barn doors with air operated rear door safety lock
2000x1000 x 3mm internal wear plates for extra resistance
Unique wider extruded planks that are fully seam welded (many competitors reduce cost by only stitch welding - not advised in plank side construction!)
Full robot side welding, door welding and headboard welding for perfection every time
Conical body shape gives a better discharge
Front headboard sidewall cast alloy joiners which prevent the headboard from splitting away
4 extra cross members at rear of trailer for forklift loading
UK reinforced lead up plate and a heavy duty king pin, 18 tonne capability (Knapen being Dutch are used to 55 tonne total weight)
Moving internal headboard
2 year paint warranty!
Wander lead remote control
Side impact bars and rear underrun bar
Catwalk and toolbox
120 cuyd on a K100 steel galvanised chassis – 10 Year rust warranty
Tri axle on air
SAF off-road axles and SAF disc brakes
21 plank x 10mm Floor which is the stronger aluminium flat Cargo Floor system, compared to the 6mm version
Dawbarn Hydroclear automatic sheet system - 900g sheet!
50:50 barn doors with air operated rear door safety lock
2000x1000 x 3mm internal wear plates for extra resistance
Unique wider extruded planks that are fully seam welded (many competitors reduce cost by only stitch welding - not advised in plank side construction!)
Full robot side welding, door welding and headboard welding for perfection every time
Conical body shape gives a better discharge
Front headboard sidewall cast alloy joiners which prevent the headboard from splitting away
4 extra cross members at rear of trailer for forklift loading
UK reinforced lead up plate and a heavy duty king pin, 18 tonne capability (Knapen being Dutch are used to 55 tonne total weight)
Moving internal headboard
2 year paint warranty!
Wander lead remote control
Side impact bars and rear underrun bar
Catwalk and toolbox
