| Year | 2019 |
|---|---|
| Chassis | Knapen Trailers BV. |
| Body | Knapen Trailers BV. |
| Volume | 127 CuYds (97.1m3) |
| Weight | 8400kgs |
| Stock No. | SN13344 |
|---|---|
| Type | Recycling Moving Floor Trailer |
| Chassis | Knapen |
| Body | Knapen |
| Year | 2019 |
| MOT | 09/2026 C517787 |
| Documents |  Parts Manual |
| eCO2 | 85000kg |
|---|---|
| Confidence | 1 (low) |
| Checked | 16/11/2022 |
| Weight | 8400kgs |
|---|---|
| Type | Steel Sub-Frame |
| Suspension | Air |
| Brakes | 22.50" BPW Drum |
| ABS/EBS | WABCO EBS-E |
| Wheels | Steel |
| Axles | 3x BPW Eco Plus |
| Volume | 127 CuYds (97.1m3) |
|---|---|
| Door | Barn Door 50:50 |
| Catwalk |  |
| Floor System | Cargo CF500SL-C |
| Floor Slats | 15x 18mm HDI |
| Floor Parts | HDI |
| Headboard | Moving |
| Chassis | Galvanised |
| Body | RAL 9010 White |
| Cover | Seawolf Blue (Grey) Dawbarn Hydraulic Roll Over Sheet Hydroclear |
127 cuyd 4.2m over the side
K100 Baltic Chassis (18 tonne pin construction). This trailer was originally designed to cope with the heavy use and poor roads of the Baltic states. The kinpin has steel construction and extra bearers compared to the BIOMASS and Standard floors.
Cargo Floor 21 plank system
Heavy Duty Impact plank system 8mm - 18mm of aluminium
1200 floor bearers (upgraded from 800 on standard trailer)
Thicker than standard cross members full length
8 additional cross members than standard
Heavy duty UK steel lead up plate
BPW and BPW drum brake axles
Galvanised chassis with 10 year anti corrosion warranty
2m (H) x 3m (L) + 1m (H) x 3m (L) 4 mm wear plates to rear sidewalls
Steel capped top rails 600 mm x 600 mm x 6 mm steel box capping both sides, front and rear attached by tabs and bolts.
Extra heavy duty Central roof support
Moving internal headboard
Towing eye in case you have been a bit cheeky
Dawbarn Hydroclear automatic sheet system
Rear door 50 50 split with double locks per door (hydraulic door variant available to order) with an automatic safety door lock.
Front catwalk
Knapen Waste Specification Walking Floor
127 cuyd 4.2m over the side
K100 Baltic Chassis (18 tonne pin construction). This trailer was originally designed to cope with the heavy use and poor roads of the Baltic states. The kinpin has steel construction and extra bearers compared to the BIOMASS and Standard floors.
Cargo Floor 21 plank system
Heavy Duty Impact plank system 8mm - 18mm of aluminium
1200 floor bearers (upgraded from 800 on standard trailer)
Thicker than standard cross members full length
8 additional cross members than standard
Heavy duty UK steel lead up plate
BPW and BPW drum brake axles
Galvanised chassis with 10 year anti corrosion warranty
2m (H) x 3m (L) + 1m (H) x 3m (L) 4 mm wear plates to rear sidewalls
Steel capped top rails 600 mm x 600 mm x 6 mm steel box capping both sides, front and rear attached by tabs and bolts.
Extra heavy duty Central roof support
Moving internal headboard
Towing eye in case you have been a bit cheeky
Dawbarn Hydroclear automatic sheet system
Rear door 50 50 split with double locks per door (hydraulic door variant available to order) with an automatic safety door lock.
Front catwalk
Knapen Waste Specification Walking Floor
