| Year | 2023 |
|---|---|
| Chassis | Luck Fahrzeugbau |
| Body | Luck Fahrzeugbau |
| Volume | 76 CuYds (58.1m3) |
| Weight | 8100kgs |
| Stock No. | SN17636 |
|---|---|
| Type | Steel Body Tipping Trailer |
| Chassis | Lück |
| Body | Lück |
| Model | 76 4 4 net FSS57 |
| Year | 2023 |
| MOT | 11/2026 C610384 |
| Documents |  Parts Manual |
| eCO2 | 55000kg |
|---|---|
| Confidence | 1 (low) |
| Checked | 16/11/2022 |
| Weight | 8100kgs |
|---|---|
| Type | Steel Step Frame |
| Suspension | Air |
| Brakes | 22.50" SAF SBS Disc |
| ABS/EBS | WABCO EBS-E |
| Wheels | Steel |
| Weigher | VWS |
| Axles | 3x SAF BI9 22S SBS |
| Volume | 76 CuYds (58.1m3) |
|---|---|
| Door | Barn Door 50:50 |
| Catwalk |  |
| Chassis | DAF Grau C4P500 |
| Body | RAL 7012 Basalt Grey |
| Cover | Net Green Dawbarn Manual Net System 50:50 Split |
Newton Luck Steel Tipping Trailer - The Lightest Steel Body Trailer in the UK Market
76 cuyd - Hardox steel body on Hardox steel step frame chassis
5 mm Hardox Floor - single piece full length - no joins for strength
4 mm Hardox Side - laser cut and laser welded - single sheets full length with no joins for strength
Hardox rear door
50:50 barn door with pneumatic door locking mechanism with 5 hinges
Triaxle on air with a front lift axle
VWS weighing system
Front Catwalk (UK NS drop)
Landing legs aluminium LG
Dawbarn manual net system Split 50:50 front wound from the ground
Newton Luck Steel Tipping Trailer - The Lightest Steel Body Trailer in the UK Market
76 cuyd - Hardox steel body on Hardox steel step frame chassis
5 mm Hardox Floor - single piece full length - no joins for strength
4 mm Hardox Side - laser cut and laser welded - single sheets full length with no joins for strength
Hardox rear door
50:50 barn door with pneumatic door locking mechanism with 5 hinges
Triaxle on air with a front lift axle
VWS weighing system
Front Catwalk (UK NS drop)
Landing legs aluminium LG
Dawbarn manual net system Split 50:50 front wound from the ground
