| Year | 2022 |
|---|---|
| Chassis | Luck Fahrzeugbau |
| Body | Luck Fahrzeugbau |
| Volume | 90 CuYds (68.8m3) |
| Weight | 8390kgs |
| Stock No. | SN19320 |
|---|---|
| Type | Steel Body Tipping Trailer |
| Chassis | Lück |
| Body | Lück |
| Model | 90 4 4 Net FSS68 |
| Year | 2022 |
| MOT | C584811 |
| Documents |  Parts Manual |
| eCO2 | 55000kg |
|---|---|
| Confidence | 1 (low) |
| Checked | 16/11/2022 |
| Weight | 8390kgs |
|---|---|
| Type | Steel Step Frame |
| Suspension | Air |
| Brakes | 22.50" SAF SBS Disc |
| ABS/EBS | WABCO EBS-E |
| Wheels | Steel |
| Weigher | VWS |
| Axles | 3x SAF BI9 22S SBS |
| Axle 1 | Lift |
| Axle 2 | Fixed |
| Axle 3 | Fixed |
| Volume | 90 CuYds (68.8m3) |
|---|---|
| Door | Barn Door 50:50 |
| Catwalk |  |
| Chassis | Daf C4P500 Grey |
| Body | Aircraft Blue BS108 |
| Cover | Dawbarn Electric Net System Front to Back |
Newton Luck Steel Tipping Trailer - The Lightest Steel Body Trailer in the UK Market
90 cuyd - this is our larger variant (most people purchase the 75 cu yd - but if you like it your way this is the large one)
5 mm Hardox Floor - 500 Hb - Hardness Brinnell - very hard steel - the floor is fitted as one length with no joins for strength
4/3 mm Hardox Side Laser cut and laser welded construction. The side is fitted as one length no joins between panels - for strength. 4mm for the lower two thirds of the side, 3 mm for the upper section
Ribs - Hardox - for strength - one of the many reasons the LUCK works and the others do not
50:50 Split Barn Doors - with additional automatic door lock for driver protection. Driver stands clear and releases door from an air switch
5 hinges per door - for strength
Hardox Doors - no we do not drop to cheaper steel on the doors
SAF Axles with SAF Disc brakes
Tri axle on air with a front lift axle
VWS wifi weighing system
Front catwalk
Alloy landing legs - Saving 80kgs per load
50:50 Barn doors with air safety catch
Electric front to back net system
90 cuyd - this is our larger variant (most people purchase the 75 cu yd - but if you like it your way this is the large one)
5 mm Hardox Floor - 500 Hb - Hardness Brinnell - very hard steel - the floor is fitted as one length with no joins for strength
4/3 mm Hardox Side Laser cut and laser welded construction. The side is fitted as one length no joins between panels - for strength. 4mm for the lower two thirds of the side, 3 mm for the upper section
Ribs - Hardox - for strength - one of the many reasons the LUCK works and the others do not
50:50 Split Barn Doors - with additional automatic door lock for driver protection. Driver stands clear and releases door from an air switch
5 hinges per door - for strength
Hardox Doors - no we do not drop to cheaper steel on the doors
SAF Axles with SAF Disc brakes
Tri axle on air with a front lift axle
VWS wifi weighing system
Front catwalk
Alloy landing legs - Saving 80kgs per load
50:50 Barn doors with air safety catch
Electric front to back net system
| Stock No. | SN19320 |
|---|---|
| Type | Steel Body Tipping Trailer |
| Chassis | Lück |
| Body | Lück |
| Model | 90 4 4 Net FSS68 |
| Year | 2022 |
| MOT | C584811 |
| Documents | Parts Manual |
| eCO2 | 55000kg |
|---|---|
| Confidence | 1 (low) |
| Checked | 16/11/2022 |
| Weight | 8390kgs |
|---|---|
| Type | Steel Step Frame |
| Suspension | Air |
| Brakes | 22.50" SAF SBS Disc |
| ABS/EBS | WABCO EBS-E |
| Wheels | Steel |
| Weigher | VWS |
| Axles | 3x SAF BI9 22S SBS |
| Axle 1 | Lift |
| Axle 2 | Fixed |
| Axle 3 | Fixed |
| Volume | 90 CuYds (68.8m3) |
|---|---|
| Door | Barn Door 50:50 |
| Catwalk | |
| Chassis | Daf C4P500 Grey |
| Body | Aircraft Blue BS108 |
| Cover | Dawbarn Electric Net System Front to Back |
